Production Chambers, Temperature Chambers, Temperature Humidity Chambers |
CH |
386L |
CSZ |
ZPHS-8-1.5-H/AC |
24 |
24 |
24 |
|
CSZ Temperature Humidity Test Chamber
Climate Chamber
Model #ZPHS-8-1.5-H/AC SHORT LEAD TIME!
SALE PENDING...
SPECS:
I.D. 24"W X 24"D X 24"H
O.D. 40"W X 61"D X 77"H
Temperature Range: -34 to +190 Deg. C - Air Cooled
10% to 95% Humidity - Has Water Recycling System
Watlow Model F-4 Programmer
CAN BE UPGRADED TO THE WATLOW F4T TOUCHSCREEN CONTROL
Temperature Limit Control
Environmentally Friendly Refrigerants
Stainless Steel Interior
1 Shelf Included
1X 3.75" Dia. Feed-Thru Port
2X 12" X 2" Dia. Alternate Side Feed-Thru Ports
Power: 208V, 3Ph, 28 Amps
Stock #386L
|
Spec sheet:
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers |
CT |
387L |
TENNEY |
T2C |
15.5 |
13 |
16 |
|
Tenney Temperature Chamber Model #T2C
SPECS:
I.D. 15.5"W X 13"D X 16"H
O.D. 26"W X 26"D X 65"H
Temperature Range: -75 to +200 Deg. C - Air Cooled
Has Watlow Model 942 Programmer
CAN BE UPGRADED TO THE WATLOW F4T
Environmentally Friendly Refrigerants
Stainless Steel Interior
Has Castors, 1 FREE Shelf
3.5" Dia. Side Feed-Thru Port
Power: 120V, 20 Amps
Stock #387L
|
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers, Temperature Humidity Chambers |
CH |
414L |
CSZ |
ZPHS-8-1.5-1-H/AC |
24 |
24 |
24 |
|
CSZ Temperature Humidity Test Chamber
Model #ZPHS-8-1.5-1-H/AC
SPECS:
I.D. 24"W X 24"D X 24"H
O.D. 40"W X 61"D X 77"H
Temperature Range: -70 to +170 Deg. C
20% to 95% Humidity
Water Recycling System With Pump & Filter
Has CSZ Model #570 Touchscreen Control
Over and Under Temperature Protection
Environmentally Friendly Refrigerants
Stainless Steel Interior
Includes Window, Interior Light, Castors, 1 Shelf
1X 4" Dia. Feed-Thru Port
Power: 208V, 3Ph, 20.1 Amps
Stock #414L
|
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers, Temperature Humidity Chambers |
CH |
415L |
CSZ |
ZPHS-8-1.5-1-H/AC |
24 |
24 |
24 |
|
CSZ Temperature Humidity Test Chamber
Model #ZPHS-8-1.5-1-H/AC
SPECS:
I.D. 24"W X 24"D X 24"H
O.D. 40"W X 61"D X 77"H
Temperature Range: -70 to +170 Deg. C
20% to 95% Humidity
Water Recycling System With Pump & Filter
Has CSZ Model #570 Touchscreen Control
Over and Under Temperature Protection
Environmentally Friendly Refrigerants
Stainless Steel Interior
Includes Window, Interior Light, Castors, 1 Shelf
1X 4" Dia. Feed-Thru Port
Power: 208V, 3Ph, 20.1 Amps
Stock #415L
|
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers |
CT |
401L |
TENNEY |
T30C-1.5 |
36 |
40 |
36 |
|
Tenney Temperature Chamber Model #T30C-1.5
SALE PENDING...
SPECS:
I.D. 36"W X 40"D X 36"H
O.D. 46"W X 60"D X 87"H
Temperature Range: -73 to +200 Deg. C - Air Cooled
1 Pass Airflow
Has Watlow Model #F4 Programmer
Environmentally Friendly Refrigerants
Stainless Steel Interior
Chamber Has Castors For Easy Movement
6" Dia. Feed-Thru Port On Left Side
2" Dia. Feed-Thru Port On Left Side
Power: 208V, 1Ph, 35 Amps
(45 Amp Fuse Recommended)
Stock #401L
|
|
|
|
Production Chambers, Temperature Chambers, Bench Top Temperature Chambers |
CT |
826J |
CSZ |
Z2-033-033-H/AC |
20 |
13 |
14 |
|
CSZ Temperature Test Chamber Model #Z2-033-033-H/AC
SPECS:
I.D. 20"W X 13"D X 14"H
O.D. 32"W X 34"D X 48"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
NEW Compressors
NEW Watlow F4T Touchscreen Control
Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes 1 Shelf - ADDITIONAL SHELVES AVAILABLE
2X 3" Dia. Side Feed-Thru Ports
Power: 120V, 20 Amps
Stock #826J
|
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers |
CT |
368J |
CSZ |
CTS-28-3-3-LN2-H/AC |
66 |
20 |
36 |
|
CSZ Temperature Chamber
Model CTS-28-3-3-LN2-H/AC
SPECS:
I.D. 66"W X 20"D X 36"H
O.D. 114"W X 58"D X 82"H
Temperature Range: -60 to +170 Deg. C
LN2 Boost
Watlow #F4T Touchscreen programmer
Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
4X 3" Dia. Top Feed Thru Ports, Castors
Power: 208V, 3Ph, 80 Amps
INCLUDES OUR 100% PARTS AND LABOR WARRANTY
Stock #368J
|
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers |
CT |
392L |
TENNEY |
TJR |
16 |
11 |
12 |
|
Tenney Temperature Chamber Model #TJR
Compact Bench Top Test Chamber
Test Results Posted - READY TO SHIP TODAY!
SPECS:
I.D. 16"W X 11"D X 12"H
O.D. 37"W X 23"D X 30"H
Temperature Range: -70 to +170 Deg C - Air Cooled
Has NEW Watlow Model #F4T Touchscreen Control
1 Shelf, 1X 2" Dia. Side Port
Includes Custom Built - Powder Coated Heavy Duty Cart With Casters
Power: 120V, 1Ph, 20 Amps
Stock #392L
|
Spec sheet:
Manual:
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers |
CT |
322J |
TENNEY |
T-64SPL |
48 |
48 |
48 |
|
Tenney Temperature Test Chamber Model #T-64SPL
64 CUBIC FT. INTERIOR
SPECS:
I.D. 48"W X 48"D X 48"H
O.D. 72"W X 81"D X 94"H
New Watlow Model F4T Touchscreen Programmer
With Charting And Graphing Capabilities
Temperature Limit Control
Temperature Range: -70 to +170 Deg. C (Water Cooled)
Environmentally Friendly Refrigerants
New Compressors - New Refrigeration Components
New Water Cooled Condenser
Viewing Window, Interior Light, Shelf
2X 8" X 12" Side Feed-Thru Ports
Power: 480V, 3Ph, 60 Amps
INCLUDES OUR 100% PARTS AND LABOR WARRANTY
Stock #322J
|
Spec sheet:
|
|
|
Climate Chambers, Industrial Ovens, Production Chambers, Temperature Chambers |
CT |
321J |
TENNEY |
T-64SPL |
48 |
48 |
48 |
|
Tenney Temperature Test Chamber Model #T-64SPL
64 CUBIC FT. INTERIOR
SPECS:
I.D. 48"W X 48"D X 48"H
O.D. 72"W X 81"D X 94"H
New Compressors
Multiple New Refrigeration Parts
New Water Cooled Condenser
New Watlow F4T Touchscreen Programmer
With Charting And Graphing Capabilities
Temperature Range: -70 to +170 Deg. C (Water Cooled)
Environmentally Friendly Refrigerants
Viewing Window, Interior Light, Shelf
2 8" X 12" Side Feed-Thru Ports
Power: 480V, 3Ph, 60 Amps
INCLUDES OUR 100% PARTS AND LABOR WARRANTY
Stock #321J
|
Spec sheet:
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers |
CT |
348L |
THERMOTRON |
SE-3000-15-15-RAC |
48 |
72 |
52 |
|
LARGE Thermotron Temperature Test Chamber
Model #SE-3000-15-15-RAC SALE PENDING...
SPECS:
I.D. 48"W X 72"D X52"H
O.D. 56"W X116"D X 95"H
Temperature Range: -70 to +180 Deg. C
Remote Air Cooled - Remote Condenser Included
Includes LN2 Boost, Has Air Inlet
Thermotron Model #8800 Touchscreen Control
Ethernet Compatible
Has Viewing Window, Interior Light
4X 45" X 22.5" Shelves Equals 1 Complete Bottom Shelf
2X 13" X 18" Opposing Side Doors
4X 6" Dia. Feed-Thru Ports - 2 On Each Opposing Side
Power: 480V, 3Ph, 70 Amps, 12 KW
Stock #348L
|
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers |
CT |
389L |
TENNEY |
TUJR |
15.625 |
11 |
11.75 |
|
Used - Refurbished Tenney Temperature Chamber
Model #TUJR
SPECS:
I.D. 15.625"W X 11"D X 11.75"H
O.D. 26"W X 22"D X 60"H
Temperature Range: -75 to +200 Deg. C - Air Cooled
Has Watlow Model #942 Programmer
CAN BE UPGRADED TO WATLOW F4T TOUCHSCREEN CONTROL
Environmentally Friendly Refrigerants
Stainless Steel Interior
Has Castors For Easy Movement
2" Dia. Side Feed-Thru Port
Power: 115V, 1Ph, 20 Amps
Stock #389L
Chamber Includes Custom Manual, Tech Support, FREE Training If Needed, 30 Point Checkout, And Of Course Our Parts & Labor Warranty
|
Spec sheet:
|
|
|
Climate Chambers, Production Chambers, Temperature Chambers |
CT |
388L |
TENNEY |
TUJR |
16 |
11 |
12 |
|
Tenney Temperature Chamber Model #TUJR
SPECS:
I.D. 16"W X 11"D X 12"H
O.D. 26"W X 22"D X 60"H
Temperature Range: -75 to +200 Deg. C - Air Cooled
Has Watlow Model #942 Programmer
CAN BE UPGRADED TO THE WATLOW F4T CONTROL
PLEASE INQUIRE
Has Castors And Includes 1 Free Shelf
3.75" Dia. Side Feed-Thru Port
Power: 120V, 1Ph, 20 Amps
Stock #388L
With 1.2 Cubic Ft Of Interior Workspace, The Tenney TUJR Is A Popular Choice For A Smaller Temperature Chamber. The Upright Design Conserves Space In Your Facility, No Table Top Or Stand Needed. For Decades Tenney Brand Chambers Have Proven To Be Reliable For Years. Of Course Our Chambers Include Our Parts And Labor Warranty To Assure Confidence Purchasing A Refurbished Chamber.
|
Spec sheet:
|
|
|
Altitude Chambers, Temperature Chambers, Temperature Humidity Chambers |
AT |
395L |
CSZ |
CAH8-3-3-S/AC |
24 |
24 |
24 |
|
CSZ Altitude Chamber - Temperature & Humidity
Model #CAH8-3-3-S/AC SALE PENDING...
SPECS:
I.D. 24"W X 24"D X 24"H
O.D. 51"W X66"D X 89"H
Temperature Range: -68 to +170 Deg. C
10% to 95% Humidity
Can Simulate Altitude Up To 100,000 Ft. (8.2 Torr)
Kinney Vacuum Pump Included - 2X 3 HP Compressors
Touchscreen Controller, Temperature Limit Control
Environmentally Friendly Refrigerants
Stainless Steel Interior
Castors, 2X 2.75" Dia. Sealed Side Ports
Power: 460V, 3Ph, 27 Amps
Stock #395L
Bargain Priced Altitude Chamber - Refurbished/Warranteed - To Test Your Components In A Multitude Of Industries - Military, Aerospace, Automotive, Electronics, More. Simulate Conditions Your Products May Encounter.
Can Also Be Used As Temperature/Humidity Cycling Chambers When Altitude Not Needed. A Great Investment For Your Company - Will Save You $1000's
|
|
|
|
Climate Chambers, CO2 LN2 Chambers, Temperature Chambers |
CA |
961J |
THERMOTRON |
F-32-CHV-LN2 |
40 |
40 |
36 |
|
Thermotron Fast Ramp Temperature Chamber
Model #F-32-CHV-LN2
SPECS:
I.D. 40"W X 40"D X 36"H
O.D. 64"W X 54"D X 108"H
Temperature Range: -70 to +170 Deg. F - LN2 Cooled
Fast Ramp: -54C to +71C 10 Deg. C Per Minute
+71C to -54C 10 Deg. C Per Minute
Will Be Equipped With Watlow Model F4T Touchscreen Control
Temperature Limit Control
Stainless Steel Interior
Honeywell Paper Chart Recorder
Viewing Windows, Interior Light, 2 Door Pass Thru
Solid Floor
Power: 208V, 3Ph, 123 Amps
Stock #961J
This Thermotron Test Chamber was originally designed as an AGREE Chamber with front and rear doors but with the solid installed floor, it can be also used as a Fast Ramp Temperature Test Chamber. It has been reconfigured with LN2 and boosted elements to meet fast ramp requirements of 10 Deg. C per minute (limited range). This Test Chamber has a separate control console with a Thermotron Model #4800 Programmer, High-Low Limit, Honeywell Chart Recorder, and comes with a Custom Operating Manual
SOME OPTIONS AVAILABLE: A Plenum floor to fit over a vibration system,
Watlow Touch Screen Programmer - These ptions that can installed by our Qualified Test Chamber Experts. Vibration Systems Also Available!
|
Spec sheet:
|
|
