| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
BA |
PORT |
STAINLESS STEEL OVEN-CHAMBER PORTS |
|
|
|
|
|
Need To Add A Feed-Thru Port To Your Oven or Test Chamber?
We Have Available Stainless Steel Ports That Can Be
Used For Many Types of Ovens And Test Chambers
Our Ports Are Made of Stainless Steel With Port Plugs
Also Available. Let Us Know The Diameter And Sleeve
Depth You Need And We Will Provide A Quote!
Have A Port Added To Your Oven Or Chamber On Order As
An Option - OR - Order Ports For You To Add To Equipment
You Already Own! Many Can Ship The Same Day!
Stock #Port
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
984J |
THERMOTRON |
SM-16-3800 |
30 |
30 |
30 |
|
Thermotron Temperature Humidity Test Chamber
Model #SM16-3800
SPECS:
I.D. 30"W X 30"D X 30"H
O.D. 56"W X 58"D X 90"H - With Transformer
Temperature Range: -70 to +170 Deg. C - Air Cooled
Humidity Range: 20% to 95% Humidity
Watlow Model #F-4T Programmer
Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Honeywell Truline Chart Recorder
Graphing & Tracking Capabilities
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAILABLE - PLEASE INQUIRE
2X 6" Dia. Feed Thru Ports
Power: 480V, 3Ph, 25 Amps
NOTE: Can Be Converted to 230V
Stock #984J
|
Spec sheet:
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
969J |
THERMOTRON |
SM-8C |
24 |
24 |
24 |
|
Thermotron Temperature Humidity Chamber
Model #SM-8C SALE PENDING...
SPECS:
I.D. 24"W X 24"D X 24"H
O.D. 48"W X 52"D X 78"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Humidity Range: 20% to 95% Humidity
Programmer, Over and Under Temperature Protection
Honeywell Truline Chart Recorder
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes 1 FREE Shelf, ADDITIONAL SHELVES AVAIL. INQUIRE
2X 4.5" Dia. Side Feed Thru Ports
Power: 208V, 3Ph, 30 Amps
Stock #969J
|
Spec sheet:
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
946J |
TENNEY |
BTRC |
20 |
20 |
20 |
|
Tenney Temperature Humidity Test Chamber
Model #BTRC
SPECS:
I.D. 20"W X 20"D X 20"H
O.D. 70"W X 34"D X 35"H
Temperature Range: -65 to +170 Deg. C
20% to 95% Humidity
Water Recycling System With Pump
WATLOW F-4T CONTROL AVAILABLE - INQUIRE
Over and Under Temperature Protection
Environmentally Friendly Refrigerants
Stainless Steel Interior
Has Honeywell DR4500 Chart Recorder
Includes 1 Shelf, 2" Dia. Feed-Thru Port - Left Side
Power: 230V, 1Ph, 23 Amps
Stock #946J
|
Spec sheet:
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
917J |
THERMOTRON |
SML-1500-25-25 |
52 |
35 |
47 |
|
Thermotron Temperature Humidity Test Chamber
Model #SML-1500-25-25
SPECS AND INCLUDED OPTIONS:
I.D. 52"W X 35"D X 47"H
O.D. 74"W X 91"D X 97"H
Temperature Range: -65 to +170 Deg. C -
Remote Air Cooled
Condenser not included.
Fast Ramp
10% to 98% Humidity
Thermotron Model 8800 Programmer
Over and Under Temperature Protection
Envirionmentally Friendly Refrigerants
Stainless Steel Interior
Honeywell Truline Recorder
Viewing Window, Interior Light, 2 Shelves
2X 6" Dia. Opposing Side Ports
Side Access Door
Power: 480V, 3Ph, 125 Amps
Stock #917J
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
874J |
TENNEY |
BTRS |
20 |
20 |
22 |
|
Tenney Temperature Humidity Test Chamber
Model #BTRS
THIS CHAMBER HAS COMPLETED ALL TESTING,
HAS NEW COMPRESSOR, AND IS READY TO SHIP TODAY!
SPECS:
I.D. 20"W X 20"D X 22"H
O.D. 57"W X 37"D X 67"H
Temperature Range: -34 to +170 Deg. C
20% to 95% Humidity
Has Water Container W/Filter
Watlow Model #F-4 Programmer
Over and Under Temperature Protection
Environmentally Friendly Refrigerants
Stainless Steel Interior
Includes Viewing Window, Stand, Castors, 1 Shelf
1.5" Dia. Side Feed-Thru Port
Power: 230V, 1Ph, 18 Amps
INCLUDES OUR PARTS & LABOR WARRANTY
Stock #874J
|
Spec sheet:
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
AA77 |
THERMOTRON |
SM-16C |
30 |
30 |
30 |
|
Thermotron Temperature Humidity Test Chamber Model SM-16C
I.D. 30"WX 30"D X 30"H
O.D. 49"W X 58"D X 84"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Humidity: 20% to 95%
Watlow #F-4 Programmer, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAILABLE - PLEASE INQUIRE
Power: 230V, 3Ph, 40 Amps
Stock #AA77
|
Spec sheet:
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
804J |
TENNEY |
TH-JR |
16 |
15 |
19 |
|
Tenney Temperature Humidity Test Chamber Model #TH-JR
I.D. 16"W X 15"D X 19"H
O.D. 46"W X 23"D X31"H
Temperature Range: -12 to +93 Deg. C
20% to 95% Humidity
Watlow #F-4 Programmer
Over Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window,
2" Dia. Side Feed-Thru Port
Power: 120V, 1Ph, 15 Amps
Stock #804J
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
LH15 |
ASSOCIATED |
LH-1.5 |
14 |
13 |
13 |
|
NEED A SMALL HUMIDITY CHAMBER? PREFER NEW?
Associated Temperature Humidity Test Chamber
Model #LH-1.5
I.D. 14"W X 13"D X 13"H
Temperature Range: +5 to +94 Deg. C (+41 to +200 F)
REVIEW ATTACHED SPEC SHEET FOR ADDITIONAL INFO
|
Spec sheet:
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CT |
SHLV |
THERMOTRON |
SHELVES |
|
|
|
|
We Provide Industrial Oven Shelves For Almost Any
Unit You May Have - Ovens - Test Chambers, Etc.
Anything We Don't Have In Stock We Can Have
Custom Created - And At Significantly Lower Prices
Than Any Vendors You May Normally Use!
Contact Us With Your Dimensions For A Quick Quote!
Fits Blue M - Thermotron - Delta Design - Tenney,
Just To Name A Few......
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
638J |
BLUE M |
AC-7702HB-1 |
37 |
18 |
23 |
|
Blue M Temperature Humidity Test Chamber Model AC-7702HB-1
I.D. 37"W X 18"D X 23"H
O.D. 55"W X 37"D X 74"H
Temperature Range: 12 Deg. C Above Ambient to 93 Deg. C
40% to 95% Humidity
Watlow 2 Channel Digital Single Set Control
Over Temperature Protection
Stainless Steel Interior
Includes Viewing Window, Stand, 1 Shelf
3" Dia. Side Feed Thru Port
Power: 208V, 1Ph, 19 Amps
Stock #638J
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CT |
MOTOR |
THERMOTRON |
MOTOR |
3.8 |
|
12.6 |
|
In Stock are these Replacement Motors for Thermotron Test Chambers
These Motors Work as a replacement motor on Most Thermotron Chambers, however we
suggest you contact us to confirm it will work on your Model
Sales@LRE.com or 800-574-2748 323-770-0634
The Motors are NEW - Not Used
Motor Dimensions: 3.8" X 5.1" with 5/16" X 7.5" Shaft
Top 3" of Shaft Flat on One Side
CWLE Stainless Steel Shaft
Power: 115/230V, 2.2/1.2 Amps, 50/60 Hz, 3000 RPM
$429.99 Each
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
578J |
TENNEY |
T10RS |
24 |
26 |
27 |
|
Tenney Temperature Humidity Test Chamber Model T10RS
I.D. 24"W X 26"D X 27"H
O.D. 43"W X 50"D X 72"H
Temperature Range: -30 to +170 Deg. C (Air Cooled)
Humidity Range: 20% to 95%
Watlow #F-4 Programmer, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Castors, Shelf
2.5" Dia. Side Feed-Thru Port, 1.5" Dia. Side Feed-Thru Port
Power: 208V, 1Ph, 30 Amps
Stock #578J
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
571J |
DESPATCH |
16507 |
20 |
24 |
24 |
|
Despatch Temperature Humidity Test Chamber Model #16507 (S)
I. D. 20"W X 24"D X 24"H
O.D. 38"W X 54"D X 75"H
Temperature Range: -29 to +177 Deg. C (Air Cooled)
Humidity Range: 20% to 95%
Watlow #F-4 Controller, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Shelf, 1.5" Dia. Side Feed-Thru Port
Power: 208V, 1Ph, 32 Amps
Stock #571J
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
544J |
TENNEY |
T6RC |
21.5 |
21 |
22.75 |
|
Tenney Temperature Humidity Test Chamber Model #T6RC
I.D. 21.5"W X 21"D X 22.75"H
O.D. 45"W X 46"D X 72"H
Temperature Range: -70 to +170 Deg. C (Air Cooled)
Humidity Range: 20% to 95%
Tenney VersaTenn III Programmer, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Viewing Window, Castors, Shelf
4" Dia. Side Feed-Thru Port
Power: 208V, 1Ph, 30 Amps
Stock #544J
|
Spec sheet:
Manual:
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
532J |
THERMOTRON |
SM-8C |
24 |
24 |
24 |
|
Thermotron Temperature Humidity Test Chamber Model #SM-8C
I.D. 24"W X 24"D X 24"H
O.D. 44"W X 50"D X 72"H
Temperature Range: -70 to +170 Deg. C
Humidity Range: 20% to 95%
Watlow #F-4 Programmer, Over and Under Temperatue Protection
Electronic Sensor
Environmentally Friendly Refrigerants, Stainless Steel Interior
Viewing Window, Interior Light, Castors, Shelf
Power: 240V, 1Ph, 30 Amps
Stock #532J
|
Spec sheet:
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CZ |
432J |
THERMOTRON |
F-40CHMV-25-25-2 |
40 |
38 |
44 |
|
Thermotron AGREE Chamber Model #F-40CHMV-25-25-2
I.D. 40"W X 38"D X 44"H
O.D. 82"W X 112"D X 95"H
Temperature Range: -65 to +170 Deg. C
Humidity Range: 20% to 95%
10 Deg. C Per Minute Non-Linear
Temperature Ramp Rate: -54 to +71 Deg. C
Water flow:Minimum 28 Gallons per minute @ 75F
Programmer, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
2X 6" Dia. Side Ports, Door Notch
Viewing Window, Shelf
Power: 460V, 3Ph, 150 Amps
Stock #432J
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
0000 |
THERMOTRON |
|
|
|
|
|
Thermotron Temperature Humdity Chamber Model #SM-5.5C
Thermotron Temperature Humdity Chamber Model #SM-8C
Thermotron Temperature Humdity Chamber Model #SM-16C
Thermotron Temperature Humdity Chamber Model #SE-600-3-3
Thermotron Temperature Humdity Chamber Model #SE-300-2-2
Chambers Will Be Completely Refurbished - Work and Look Like New
Includes Our 100% Parts AND Labor Warranty
Options Are Available
Call Now to Request A Quote - Our Experienced Sales Staff Can Help
You Choose The Right Chamber For Your Needs
We Don't Just Sell You The Equipment - We Guide You Thru The Entire Process
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
115J |
CSZ |
CTH32-6-6-RAC |
38 |
38 |
38 |
|
CSZ Temperature Humidity Chamber Model #CTH32-6-6-RAC
Internal Dimensions: 38"W X 38"D X 38"H
External Dimensions: 59" X 65"D X 103"
Temperature Range: -70 to +170 Deg. C (5 Deg. C Per Minute)
Humidity Range: 20% to 95% RH
Watlow #F-4 Control, Stainless Steel Interior
Environmentally Friendly Refrigerants
4" X 6" Door Notch
2X 5.5" Dia. Side Feed-Thru Ports, 2X 2.75" Dia. Side Feed-Thru Ports
Includes Window, Light, Filter, 1 Shelf
Remote Air Cooled, Installation Extra
Power: 480V, 3Ph, 33 Amps
Stock #115J
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
AA01 |
|
|
|
|
|
|
Thermotron Chamber Replacement Motor
This motor will replace the motor on many models of Thermotron Chambers at a fraction of the Mfg. Price.
CWLE Stainless Steel Shaft - 5/16" X 7/5" Shaft
Top 3" of Shaft Flat on One Side
Thermotron Replacement Motor Dimensions: 3.8" X 5/1"
113/230V, 2.2/1.1 Amps, 50/60 Hz, 3000 RPM
$429.00 EACH
Stock #AA01
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
300I |
ENVIROTRONICS |
EH8-2-1R |
24 |
24 |
24 |
|
Envirotronics Temperature Humidity Chamber Model #EH8-2-1R
Internal Dimensions: 24"W X 24"D X 24"H
External Dimensions: 47"W X 52"D X 78"
Temperature Range: -68 to +168 Deg. C
Humidity Range: 20% to 95% Relative Humidity
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Window, Light, Castors, 1 Shelf
2X 3" Dia. Feed-Thru Ports
Power: 230V, 3Ph, 56 Amps
Stock #CH-300I
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CZ |
294I |
BMA |
SS-16 |
30 |
30 |
30 |
|
BMA Salt Spray Chamber Model #SS-16
Internal Dimensions: 30"W X 30"D X 30"H
External Dimensions: 55"W X 41"D X 60"H
Power: 120V, 1Ph, 15 Amps
Stock #CZ-294I
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
AA28 |
CSZ |
ZH8-1-1-H/AC |
24 |
24 |
24 |
|
CSZ Temperature Humidity Chamber Model ZH8-1-1-H/AC
Internal Chamber Dimensions: 24"x24"x24"
Temperature Range: -70C to +170C (2 x 1HP Air Cooled Compressors)
Humidity Range: 20% to 95% Relative Humidity
New Watlow Model F4 Programmable Temp/Humidity Controller
Over and Under Temperature Protection Controller
Stainless Steel Interior, Window in Door, Light Inside Chamber, Castors for Easy Movement of Chamber
3" Diameter Feed-Through Port on Side of Chamber
Water Storage with Pump
Power: 208V 1PH 35A
Stock #CH-AA28
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
AA26 |
CSZ |
Z8-1-1-AC |
24 |
24 |
24 |
|
CSZ Temperature Humidity Chamber Model Z8-1-1-AC
Internal Chamber Dimensions: 24"W X 24"D X 24"H
Temperature Range: -70C to +170C (cascade air cooled compressors)
New Watlow Model 981 Programmable Controller Installed
Over and Under Temperature Protection Controller
Window in Door, Stainless Steel Interior, 2" Diameter Feed-Through Port in Side Wall
Castors for Easy Movement of Chamber, Light Inside Chamber
New Environmentally Friendly Refrigerants
Power: 208V 3PH 24A (possibility of being changed to 1PH - To be confirmed - Please Inquire)
Stock #CH-AA26
|
|
|
| Humidity Chambers, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Gravity Ovens, Curing Ovens, Heat Treat Ovens, Production Chambers, Temperature Chambers, Bench Top Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers |
CH |
AA21 |
THERMOTRON |
SM-32C |
38 |
38 |
38 |
|
Thermotron Temperature Humidity Chamber
Model #SM-32C
I.D: 38"W X 38"D X 38"H
O.D: 58"W X 66"D X 85"H
Temperature Range: -70 to +170 Deg. C (Air-Cooled)
Humidity Range: 20% to 95% Relative Humidity
New Watlow Microprocessor
Over and Under Temperature Protection
Environmentally Friendly Refrigerants
Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors
1 Shelf Included
ADDITIONAL SHELVES ALWAYS AVAILABLE - PLEASE INQUIRE
Power: 208V, 3Ph, 50 Amps
Stock #CH-AA21
|
Spec sheet:
|
|
