New Laboratory Ovens > Mechanical Convection Ovens

Mechanical Convection Ovens

New In Stock Equipment

LRE stocks New Laboratory Ovens including Mechanical Convection Ovens, Energy Saving Ovens, High Accuracy Ovens, Gravity Ovens, Inert Gas Ovens and Vacuum Ovens

Mechanical Convection Ovens have an internal fan to force heated air throughout the entire oven. Widely used for Testing and Manufacturing, these types of Mechanical Convection Ovens heat up fast and have a uniform distribution of heat. This method of heating works well with almost any size oven.


Inventory of New Mechanical Convection Ovens

Categories Class Stock No. Manufacturer Model No. Photo
Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XX55 YAMATO DKM610C Used YAMATO DKM610C Industrial Ovens/ Batch Ovens/ Laboratory Ovens/ Bench Top Ovens/ Mechanical Convection Ovens

NEW Yamato Lab Oven Model #DKM610C

Do You Need A Basic - Economical Bench Top Oven?
The NEW Yamato DKM Series Ovens May Be Just Right
Can Ship Within Days!

SPECS:
I.D. 23.6"W X 19.6"D X 19.6"H
Maximum Temperature: 260 Deg C (500 Deg. F)
Easy to Use Digital Control
Forced Air Circulation, 1.2" Feed-Thru Port,
Power: 220V, 7 Amps

Stock #XX54
Spec sheet: YAMATO DKM610C Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XX54 YAMATO DKM600C - DKM610C Used YAMATO DKM600C - DKM610C Industrial Ovens/ Batch Ovens/ Laboratory Ovens/ Bench Top Ovens/ Mechanical Convection Ovens

NEW Yamato Lab Oven Model #DKM600C

Do You Need A Basic - Economical Bench Top Oven?
The NEW Yamato DKM Series Ovens May Be Just Right
Can Ship Within Days!

SPECS:
I.D. 23.6"W X 19.6"D X 19.6"H
Maximum Temperature: 260 Deg C (500 Deg. F)
Easy to Use Digital Control
Forced Air Circulation, 1.2" Feed-Thru Port,
Power: 115V, 12 Amps Or 220V, 7 Amps

Stock #XX54
Spec sheet: YAMATO DKM600C - DKM610C Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XX52 YAMATO DKM400C - DKM410C Used YAMATO DKM400C - DKM410C Industrial Ovens/ Batch Ovens/ Laboratory Ovens/ Bench Top Ovens/ Mechanical Convection Ovens

NEW Yamato Lab Oven Model #DKM400C

Do You Need A Basic - Economical Bench Top Oven?
The NEW Yamato DKM Series Ovens May Be Just Right
Can Ship Within Days!

SPECS:
I.D. 17.7"W X 17.7"D X 17.7"H
Maximum Temperature: 260 Deg C (500 Deg. F)
Easy to Use Digital Control
Forced Air Circulation, 1.2" Feed-Thru Port,
Power: 115/220V

Stock #XX52
Spec sheet: YAMATO DKM400C - DKM410C Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XX50 YAMATO DKM300C - DKM400C - Used YAMATO DKM300C - DKM400C -  Industrial Ovens/ Batch Ovens/ Bench Top Ovens/ Mechanical Convection Ovens

NEW ECONOMICAL Yamato Lab Ovens
Models #DKM300C - DKM400C - DKM600C

Do You Need A Basic - Economical Bench Top Oven?
The NEW Yamato DKM Series Ovens May Be Just Right
Can Ship Within Days!

SPECS:
DKM300C I.D.: 11.8"W X 11.8"D X 11.8"H
DKM400C I.D.: 17.7"W X 17.7"D X 17.7"H
DKM600C I.D.: 23.6"W X 19.6"D X 19.6"H
Maximum Temperature: 260 Deg C (500 Deg. F)
Easy to Use Digital Control
Forced Air Circulation, 1.2" Feed-Thru Port,
Power: 115/220V

Stock #XX50
Spec sheet: YAMATO DKM300C - DKM400C -  Industrial Ovens, Batch Ovens, Bench Top Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XXX9 YAMATO DKN912C Used YAMATO DKN912C Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Oven
Model #DKN912C

SPECS:
I.D. 42.1"W X 19.6"D X 39.4"H - DOUBLE DOORS FOR EASY LOADING
Maximum Temperature: 210 Deg C (410 Deg. F)
INCLUDES 8 SHELVES
Power: 220V, 18 Amps

The Yamato DKN Series of Convection Ovens are our Bestseller - Based on Excellent Performance, Affordability, Superior Temperature Accuracy, and Ease of Use. The Yamato standard forced air convection ovens are programmable and come with extended functions and safety features.

The Yamato Industrial Ovens Models DKN302C/402C//602C come with observation windows and Programmable PID controllers for easy program settings - 30 step 3 pattern program controller with repeat functions. Fixed setting, programmed, Quick Auto stop, Auto stop, and Auto start operating modes with easy control capabilities. Increased safety and self-diagnostic functions. Over-heating prevention and calibration off-set are possible with auxiliary functions. Built In Exhaust Ports on all units.

Yamato Lab Ovens Purchased from LR Environmental/LR Technologies Can Be Retrofitted with a Variety of Options. Custom Feed-Thru Ports, Extra Shelves, Custom Stands. Many Ovens can also be SHIPPED THE SAME DAY! Our Oven Experts can help you choose the Right Oven for Your Needs!

Stock #XXX9
Spec sheet: YAMATO DKN912C Mechanical Convection Ovens spec sheet Manual:YAMATO DKN912C Mechanical Convection Ovens manual

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XXX2 YAMATO DKN302C - DKN132C Used YAMATO DKN302C - DKN132C Laboratory Ovens/ Bench Top Ovens/ Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Oven
Model #DKN302C & DKN312C

SPECS:
I.D. 11.8"W X 11.8"D X 11.8"H
Maximum Temperature: 260 Deg C (500 Deg. F)
Power: 115V, 7.5 Amps - 220V, 4.5 Amps

The Yamato DKN Series of Convection Ovens are our Bestseller - Based on Excellent Performance, Affordability, Superior Temperature Accuracy, and Ease of Use. The Yamato standard forced air convection ovens are programmable and come with extended functions and safety features.

The Yamato Industrial Ovens Models DKN302C/402C//602C come with observation windows and Programmable PID controllers for easy program settings - 30 step 3 pattern program controller with repeat functions. Fixed setting, programmed, Quick Auto stop, Auto stop, and Auto start operating modes with easy control capabilities. Increased safety and self-diagnostic functions. Over-heating prevention and calibration off-set are possible with auxiliary functions. Built In Exhaust Ports on all units.

Yamato Lab Ovens Purchased from LR Environmental/LR Technologies Can Be Retrofitted with a Variety of Options. Custom Feed-Thru Ports, Extra Shelves, Custom Stands. Many Ovens can also be SHIPPED THE SAME DAY! Our Oven Experts can help you choose the Right Oven for Your Needs!

Stock #XXX2
Spec sheet: YAMATO DKN302C - DKN132C Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens spec sheet Manual:YAMATO DKN302C - DKN132C Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens manual

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XXX4 YAMATO DKN402C - DKN602C Used YAMATO DKN402C - DKN602C Laboratory Ovens/ Bench Top Ovens/ Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Ovens
Models #DKN402C & DKN602C

SPECS:
DKN402C I.D.: 17.7"W X 17.7"D X 17.7"H
DKN602C I.D.: 23.6"W X 19.6"D X 19.6"H
Maximum Temperature: 260 Deg C (500 Deg. F)
Power: 115/220V

The Yamato DKN Series of Convection Ovens are our Bestseller - Based on Excellent Performance, Affordability, Superior Temperature Accuracy, and Ease of Use. The Yamato standard forced air convection ovens are programmable and come with extended functions and safety features.

The Yamato Industrial Ovens Models DKN302C/402C//602C come with observation windows and Programmable PID controllers for easy program settings - 30 step 3 pattern program controller with repeat functions. Fixed setting, programmed, Quick Auto stop, Auto stop, and Auto start operating modes with easy control capabilities. Increased safety and self-diagnostic functions. Over-heating prevention and calibration off-set are possible with auxiliary functions. Built In Exhaust Ports on all units.

Yamato Lab Ovens Purchased from LR Environmental/LR Technologies Can Be Retrofitted with a Variety of Options. Custom Feed-Thru Ports, Extra Shelves, Custom Stands. Many Ovens can also be SHIPPED THE SAME DAY! Our Oven Experts can help you choose the Right Oven for Your Needs!

Stock #XXX4
Stock #XXX6
Spec sheet: YAMATO DKN402C - DKN602C Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens spec sheet Manual:YAMATO DKN402C - DKN602C Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens manual

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XXX6 YAMATO DKN602C Used YAMATO DKN602C Laboratory Ovens/ Bench Top Ovens/ Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Ovens
Model #DKN402c & DKN602C

SPECS:
DKN402C I.D.: 17.7"W X 17.7"D X 17.7"H
DKN602C I.D.: 23.6"W X 19.6"D X 19.6"H
Maximum Temperature: 260 Deg C (500 Deg. F)
Power: 115/220V

The Yamato DKN Series of Convection Ovens are our Bestseller - Based on Excellent Performance, Affordability, Superior Temperature Accuracy, and Ease of Use. The Yamato standard forced air convection ovens are programmable and come with extended functions and safety features.

The Yamato Industrial Ovens Models DKN302C/402C//602C come with observation windows and Programmable PID controllers for easy program settings - 30 step 3 pattern program controller with repeat functions. Fixed setting, programmed, Quick Auto stop, Auto stop, and Auto start operating modes with easy control capabilities. Increased safety and self-diagnostic functions. Over-heating prevention and calibration off-set are possible with auxiliary functions. Built In Exhaust Ports on all units.

Yamato Lab Ovens Purchased from LR Environmental/LR Technologies Can Be Retrofitted with a Variety of Options. Custom Feed-Thru Ports, Extra Shelves, Custom Stands. Many Ovens can also be SHIPPED THE SAME DAY! Our Oven Experts can help you choose the Right Oven for Your Needs!

Stock #XXX4
Stock #XXX6
Spec sheet: YAMATO DKN602C Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens spec sheet Manual:YAMATO DKN602C Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens manual

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XXX8 YAMATO DKN812C Used YAMATO DKN812C Laboratory Ovens/ Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Oven
Model #DKN812C

SPECS:
I.D. 23.6"W X 19.6"D X 39.4"H
INCLUDES 4 SHELVES
Maximum Temperature: 260 Deg C (500 Deg. F)
Power: 220V, 15 Amps

The Yamato DKN Series of Convection Ovens are our Bestseller - Based on Excellent Performance, Affordability, Superior Temperature Accuracy, and Ease of Use. The Yamato standard forced air convection ovens are programmable and come with extended functions and safety features.

The Yamato Industrial Ovens Models DKN302C/402C//602C come with observation windows and Programmable PID controllers for easy program settings - 30 step 3 pattern program controller with repeat functions. Fixed setting, programmed, Quick Auto stop, Auto stop, and Auto start operating modes with easy control capabilities. Increased safety and self-diagnostic functions. Over-heating prevention and calibration off-set are possible with auxiliary functions. Built In Exhaust Ports on all units.

Yamato Lab Ovens Purchased from LR Environmental/LR Technologies Can Be Retrofitted with a Variety of Options. Custom Feed-Thru Ports, Extra Shelves, Custom Stands. Many Ovens can also be SHIPPED THE SAME DAY! Our Oven Experts can help you choose the Right Oven for Your Needs!

Stock #XXX8
Spec sheet: YAMATO DKN812C Laboratory Ovens, Mechanical Convection Ovens spec sheet Manual:YAMATO DKN812C Laboratory Ovens, Mechanical Convection Ovens manual

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx39 YAMATO DNF301 Used YAMATO DNF301 Laboratory Ovens/ Bench Top Ovens/ Energy Saving Ovens/ Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Oven
Model #DNF301
I.D. 11.8"W X 11.8"D X 11.8"H
Maximum Temperature: 270 Deg C (518 Deg. F)
Variable Flow Rate, Includes 2 Shelves
Power: 115V, 7.5 Amps

OPERATION AND FUNCTIONS:
The first 2 in 1 system in the industry
Two types of circulation, forced and natural convection, in one
unit (compatible with model 300/400/600)
Eco-oven with improved air velocity control system and
adjustable damper
Program featured to reduce power consumption significantly
Superior heat tightness and insulation of chamber
Excellent dust tightness, dust can hardly enter the chamber
Air velocity changeable in 10 stages using digital setting of
controller
Standard with 99 step program operation with repeat
operation, auto start, auto stop and quick auto stop functions
Adjustable damper position at chamber front to optimize operation
Fluorescent display, interactive input method, calibration off-
set function
Spec sheet: YAMATO DNF301 Laboratory Ovens, Bench Top Ovens, Energy Saving Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO XX40 YAMATO DNF401 - DNF411 Used YAMATO DNF401 - DNF411 Laboratory Ovens/ Bench Top Ovens/ Energy Saving Ovens/ Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Oven
Models #DNF401 & DNF411
I.D. 17.7"W X 17.7"D X 17.7"H
Maximum Temperature: 270 Deg C (518 Deg. F)
Variable Flow Rate, Includes 2 Shelves
Power: 115V, 11 Amps - 220V, 6 Amps

OPERATION AND FUNCTIONS:
The first 2 in 1 system in the industry
Two types of circulation, forced and natural convection, in one
unit (compatible with model 300/400/600)
Eco-oven with improved air velocity control system and
adjustable damper
Program featured to reduce power consumption significantly
Superior heat tightness and insulation of chamber
Excellent dust tightness, dust can hardly enter the chamber
Air velocity changeable in 10 stages using digital setting of
controller
Standard with 99 step program operation with repeat
operation, auto start, auto stop and quick auto stop functions
Adjustable damper position at chamber front to optimize operation
Fluorescent display, interactive input method, calibration off-
set function
Spec sheet: YAMATO DNF401 - DNF411 Laboratory Ovens, Bench Top Ovens, Energy Saving Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx42 YAMATO DNF601 - DNF611 Used YAMATO DNF601 - DNF611 Laboratory Ovens/ Bench Top Ovens/ Energy Saving Ovens/ Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Oven
ModelS #DNF601 & DNF611
I.D. 23.6"W X 19.7"D X 19.7"H
Maximum Temperature: 270 Deg C (518 Deg. F)
Variable Flow Rate, Includes 2 Shelves
Power: 115V, 15 Amps - 220V, 8 Amps

OPERATION AND FUNCTIONS:
The first 2 in 1 system in the industry
Two types of circulation, forced and natural convection, in one
unit (compatible with model 300/400/600)
Eco-oven with improved air velocity control system and
adjustable damper
Program featured to reduce power consumption significantly
Superior heat tightness and insulation of chamber
Excellent dust tightness, dust can hardly enter the chamber
Air velocity changeable in 10 stages using digital setting of
controller
Standard with 99 step program operation with repeat
operation, auto start, auto stop and quick auto stop functions
Adjustable damper position at chamber front to optimize operation
Fluorescent display, interactive input method, calibration off-
set function
Spec sheet: YAMATO DNF601 - DNF611 Laboratory Ovens, Bench Top Ovens, Energy Saving Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx44 YAMATO DNF811 Used YAMATO DNF811 Laboratory Ovens/ Energy Saving Ovens/ Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Oven
Model #DNF811
I.D. 23.6"W X 19.7"D X 39.4"H
Maximum Temperature: 270 Deg C (518 Deg. F)
Variable Flow Rate, Includes 4 Shelves
Power: 220V, 15.5 Amps

OPERATION AND FUNCTIONS:
The first 2 in 1 system in the industry
Two types of circulation, forced and natural convection, in one
unit (compatible with model 300/400/600)
Eco-oven with improved air velocity control system and
adjustable damper
Program featured to reduce power consumption significantly
Superior heat tightness and insulation of chamber
Excellent dust tightness, dust can hardly enter the chamber
Air velocity changeable in 10 stages using digital setting of
controller
Standard with 99 step program operation with repeat
operation, auto start, auto stop and quick auto stop functions
Adjustable damper position at chamber front to optimize operation
Fluorescent display, interactive input method, calibration off-
set function
Spec sheet: YAMATO DNF811 Laboratory Ovens, Energy Saving Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx45 YAMATO DNF911 Used YAMATO DNF911 Laboratory Ovens/ Energy Saving Ovens/ Mechanical Convection Ovens

NEW Yamato Industrial / Lab Forced Air Convection Oven
Model #DNF911
I.D. 42.9"W X 19.7"D X 39.4"H
Maximum Temperature: 260 Deg C (500 Deg. F)
Variable Flow Rate, Includes 8 Shelves
Power: 220V, 18.5 Amps

OPERATION AND FUNCTIONS:
The first 2 in 1 system in the industry
Two types of circulation, forced and natural convection, in one
unit (compatible with model 300/400/600)
Eco-oven with improved air velocity control system and
adjustable damper
Program featured to reduce power consumption significantly
Superior heat tightness and insulation of chamber
Excellent dust tightness, dust can hardly enter the chamber
Air velocity changeable in 10 stages using digital setting of
controller
Standard with 99 step program operation with repeat
operation, auto start, auto stop and quick auto stop functions
Adjustable damper position at chamber front to optimize operation
Fluorescent display, interactive input method, calibration off-
set function
Spec sheet: YAMATO DNF911 Laboratory Ovens, Energy Saving Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx23 YAMATO DH612 Used YAMATO DH612 Laboratory Ovens/ Mechanical Convection Ovens

NEW Yamato High Accuracy Lab Oven Model #DH612
I.D. 23.6"W X 23.6"D X 23.6"H
Max. Temperature: 360 Deg. C (680 Deg. F)
Power: 220V, 17.5 Amps

Highly reliable and accurate oven with improved
visibility and operability of control panel
Operation and functions
Precise temperature stability & uniformity
Standard equipped with adjustable air speed function and
displays of power consumption, CO 2 emission and heat
timer
Enhanced program operation function (maximum 99 steps,
99 patterns, repetitive operation function)
Improved safety with fan motor error detection
Exhaust damper allows quick exhaust and cooling of inside
chamber
Equipped with exhaust and cable ports

Safety features
Self-diagnosis circuit (abnormal temp. sensing, heater
disconnection, auto overheat prevention, SSR short circuit),
overheat protector, earth leakage breaker, key lock, etc.
Spec sheet: YAMATO DH612 Laboratory Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx22 YAMATO DH412 Used YAMATO DH412 Mechanical Convection Ovens

NEW Yamato High Accuracy Lab Oven Model #DH412
I.D. 17.7"W X 17.7"D X 17.7"H
Max. Temperature: 360 Deg. C (680 Deg. F)
Power: 220V, 15.5 Amps

Highly reliable and accurate oven with improved
visibility and operability of control panel
Operation and functions
Precise temperature stability & uniformity
Standard equipped with adjustable air speed function and
displays of power consumption, CO 2 emission and heat
timer
Enhanced program operation function (maximum 99 steps,
99 patterns, repetitive operation function)
Improved safety with fan motor error detection
Exhaust damper allows quick exhaust and cooling of inside
chamber
Equipped with exhaust and cable ports

Safety features
Self-diagnosis circuit (abnormal temp. sensing, heater
disconnection, auto overheat prevention, SSR short circuit),
overheat protector, earth leakage breaker, key lock, etc.
Spec sheet: YAMATO DH412 Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx21 YAMATO DF612 Used YAMATO DF612 Laboratory Ovens/ High Accuracy Ovens/ Mechanical Convection Ovens

NEW Yamato High Accuracy Lab Oven Model #DF612
I.D. 23.6"W X 23.6"D X 23.6"H
Max. Temperature: 260 Deg. C (500 Deg. F)
Power: 220V, 17.5 Amps

Highly reliable and accurate oven with improved
visibility and operability of control panel
Operation and functions
Precise temperature stability & uniformity
Standard equipped with adjustable air speed function and
displays of power consumption, CO 2 emission and heat
timer
Enhanced program operation function (maximum 99 steps,
99 patterns, repetitive operation function)
Improved safety with fan motor error detection
Exhaust damper allows quick exhaust and cooling of inside
chamber
Equipped with exhaust and cable ports

Safety features
Self-diagnosis circuit (abnormal temp. sensing, heater
disconnection, auto overheat prevention, SSR short circuit),
overheat protector, earth leakage breaker, key lock, etc.
Spec sheet: YAMATO DF612 Laboratory Ovens, High Accuracy Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx20 YAMATO DF412 Used YAMATO DF412 Laboratory Ovens/ High Accuracy Ovens/ Mechanical Convection Ovens

NEW Yamato High Accuracy Lab Oven Model #DF412
I.D. 17.7"W X 17.7"D X 17.7"H
Max. Temperature: 260 Deg. C (500 Deg. F)
Power: 220V, 12.5 Amps

Highly reliable and accurate oven with improved
visibility and operability of control panel
Operation and functions
Precise temperature stability & uniformity
Standard equipped with adjustable air speed function and
displays of power consumption, CO 2 emission and heat
timer
Enhanced program operation function (maximum 99 steps,
99 patterns, repetitive operation function)
Improved safety with fan motor error detection
Exhaust damper allows quick exhaust and cooling of inside
chamber
Equipped with exhaust and cable ports

Safety features
Self-diagnosis circuit (abnormal temp. sensing, heater
disconnection, auto overheat prevention, SSR short circuit),
overheat protector, earth leakage breaker, key lock, etc.
Spec sheet: YAMATO DF412 Laboratory Ovens, High Accuracy Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx19 YAMATO DH1032 Used YAMATO DH1032 Mechanical Convection Ovens

NEW Yamato High Accuracy Industrial Oven Model DH1032
I.D. 39.4"W X 39.4"D X 39.4"H
Max. Temp: 300 Deg. C
Power: 220V, 3Ph, 28 Amps

Allows precision maintenance of large parts at a
constant temperature
Quick exhaust and cooling in the unit with the exhaust
damper
Interactive key entry on the
control panel with a green LED
digital display for easy settings
Features power consumption/
CO 2 emissions monitoring
Increased safety and self diag-
nostic functions
Spec sheet: YAMATO DH1032 Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx18 YAMATO DH832 Used YAMATO DH832 Mechanical Convection Ovens

NEW Yamato High Accuracy Industrial Oven Model DH832
I.D. 31.5"W X 31.5"D X 31.5"H
Max. Temp: 300 Deg. C
Power: 220V, 3Ph, 20 Amps

Allows precision maintenance of large parts at a
constant temperature
Quick exhaust and cooling in the unit with the exhaust
damper
Interactive key entry on the
control panel with a green LED
digital display for easy settings
Features power consumption/
CO 2 emissions monitoring
Increased safety and self diag-
nostic functions
Spec sheet: YAMATO DH832 Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx17 YAMATO DF1032 Used YAMATO DF1032 Laboratory Ovens/ High Accuracy Ovens/ Mechanical Convection Ovens

NEW Yamato High Accuracy Industrial Oven Model DF1032
I.D. 39.4"W X 39.4"D X 39.4"H
Max. Temp: 200 Deg. C
Power: 220V, 3Ph, 17 Amps

Allows precision maintenance of large parts at a
constant temperature
Quick exhaust and cooling in the unit with the exhaust
damper
Interactive key entry on the
control panel with a green LED
digital display for easy settings
Features power consumption/
CO 2 emissions monitoring
Increased safety and self diag-
nostic functions
Spec sheet: YAMATO DF1032 Laboratory Ovens, High Accuracy Ovens, Mechanical Convection Ovens spec sheet

Industrial Ovens, Batch Ovens, Laboratory Ovens, Bench Top Ovens, Mechanical Convection Ovens NO xx16 YAMATO DF832 Used YAMATO DF832 Laboratory Ovens/ High Accuracy Ovens/ Mechanical Convection Ovens

NEW Yamato High Accuracy Industrial Oven Model DF832
I.D. 31.5"W X 31.5"D X 31.5"H
Max. Temp: 200 Deg. C
Power: 220V, 3Ph, 13.5 Amps

Allows precision maintenance of large parts at a
constant temperature
Quick exhaust and cooling in the unit with the exhaust
damper
Interactive key entry on the
control panel with a green LED
digital display for easy settings
Features power consumption/
CO 2 emissions monitoring
Increased safety and self diag-
nostic functions
Spec sheet: YAMATO DF832 Laboratory Ovens, High Accuracy Ovens, Mechanical Convection Ovens spec sheet

Total Results: 22
