Thermotron Test Chambers

Refurbished and customized

Thermotron is one of the most well known brands of Environmental Test Equipment and we always maintain a large stock of Thermotron Chambers. Temperature Chambers, Humidity Chambers, AGREE Chambers, and Thermal Shock Chambers are just an example of the types of Test Chambers Thermotron manufactures and we regularly have in Inventory. Always constructed with high quality steel exteriors and stainless steel interiors, Thermotron chambers have been built to last.

Need special options or modifications? We are equipped and experienced to upgrade the equipment to meet your specific requirements. Our Experienced Sales Staff will guide you every step of the way with the most up to date options and technical information.



Free Quotes!
Call or email now!

1-800-574-2748








Category Class Stock No. Manufacturer Model No. Photo
Production Chambers, Temperature Chambers CT 141L THERMOTRON S-8 Used THERMOTRON S-8

Thermotron Temperature Chamber Model #S-8

SPECS:
I.D. 24"W X 24"D X 24"H
O.D. 41"W X 47"D X 76"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Programmer, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Has Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAIL - PLEASE INQUIRE!
6" Dia. Side Feed-Thru Port, 2" Dia. Side Feed-Thru Port
Power: 208V, 3Ph, 22.1 Amps

Stock #141L
Spec sheet: THERMOTRON S-8 Production Chambers, Temperature Chambers spec sheet

Production Chambers, Temperature Chambers CT 142L THERMOTRON S-27 Used THERMOTRON S-27

Thermotron Temperature Chamber Model #S-27
THIS UNIT HAS BEEN COMPLETELY CHECKED OUT AND IS READY TO SHIP ASAP!
SALE PENDING....

SPECS:
I.D. 36"W X 36"D X 36"H
O.D. 58"W X 66"D X 92"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Has NEW Modern Watlow #F-4T Touchscreen Control
Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAIL - PLEASE INQUIRE!
2X 6" Dia. Opposing Side Ports
Power: 208V, 3Ph, 36.5 Amps

Stock #142L

Production Chambers, Temperature Chambers CT 998J THERMOTRON HPS-16 Used THERMOTRON HPS-16

Thermotron Fast Ramp Temperature Chamber
Model #HPS-16

SPECS:
I.D. 30"W X 30"D X 30"H
O.D. 72"W X 52"D X 98"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Watlow Model #F-4 Programmer, Over and Under Temperature Protection
Prefer A Touchscreen Control? Can Be Upgraded, Be Sure To Ask
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAIL - PLEASE INQUIRE!
1X 4" Dia. Side Feed-Thru Port, 1X 2.5" Dia. Side Feed-Thru Port, 18" X 6" Door Port
NEW Compressors, 5 Deg. C Per Minute Ramp Rate
Power: 460V, 3Ph, 30 Amps

Stock #998J
Spec sheet: THERMOTRON HPS-16 Production Chambers, Temperature Chambers spec sheet

Production Chambers, Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers CH 108L THERMOTRON SM-16-8200 Used THERMOTRON SM-16-8200

Thermotron Temperature Humidity Chamber
Model #SM-16-8200

HUMIDITY CHAMBER SPECS:
I.D. 30"W X 30"D X 30"H
O.D. 43"W X 60"D X 80"H
Temperature Range: -70 to +180 Deg. C - Air Cooled
10% to 98% Humidity
Has Thermotron Model #8200 Programmer
Over Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
2X 4" Dia. Side Ports
Power: 230V, 3Ph, 35.4 Amps

Stock #108L

Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers CH 109L THERMOTRON SM-16-8200 Used THERMOTRON SM-16-8200

Thermotron Temperature Humidity Chamber
Model #SM-16-8200 SALE PENDING....

THIS UNIT HAS COMPLETED OUR 30 POINT CHECKOUT/REFURBISHMENT PROCESS - HAS A NEW HIGH STAGE COMPRESSOR - AND IS READY TO SHIP!

HUMIDITY CHAMBER SPECS:
I.D. 30"W X 30"D X 30"H
O.D. 43"W X 60"D X 80"H
Temperature Range: -70 to +180 Deg. C - Air Cooled
10% to 98% Humidity
Has Thermotron Model #8200 Programmer
Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAIL - PLEASE INQUIRE!
2X 4" Side Feed-Thru Ports
Power: 230V, 3Ph, 35.4 Amps

Stock #109L

Production Chambers, Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers CH 106L THERMOTRON SM-16C Used THERMOTRON SM-16C

Thermotron Temperature Humidity Chamber
Model #SM-16C

HUMIDITY CHAMBER SPECS:
I.D. 30"W X 30"D X 30"H
O.D. 49"W X 60"D X 80"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
20% to 95% Humidity
Has Watlow Model #F-4T Touchscreen Controller
Over Temperature Protection
Environmentally Friendly Refrigeration, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAIL - PLEASE INQUIRE!
2X 4" Side Feed-Thru Ports
Power: 230V, 1Ph, 50 Amps

Stock #106L

Production Chambers, Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers CH 107L THERMOTRON SM-16-8200 Used THERMOTRON SM-16-8200

Thermotron Temperature Humidity Test Chamber
Model #SM-16-8200

HUMIDITY CHAMBER SPECS:
I.D. 30"W X 30"D X 30"H
O.D. 43"W X 60"D X 80"H
Temperature Range: -70 to +180 Deg. C - Air Cooled
10% to 98% Humidity
Has Thermotron Model #8200 Programmer
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAILABLE - PLEASE INQUIRE!
2X 4" Dia. Side Feed-Thru Ports

Stock #107L

Production Chambers, Temperature Chambers CT 980J THERMOTRON SM-32C Used THERMOTRON SM-32C

Thermotron Temperature Test Chamber
Model #SM-32C

SPECS:
I.D. 38"W X 38"D X 38"H
O.D. 62"W X 67"D X 88"H
Temperature Range: -70C to +170C (-94F to +338F)
Air Cooled, Mechanical Refrigeration
Easy To Use Watlow EZ-Zone Programmer

Can Be Upgraded With Watlow F-4T Touchscreen Programmer - BE SURE TO INQUIRE!

Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAILABLE
2X 6" Opposing Side Feed-Thru Ports
Power: 230V, 3Ph, 37 Amps

Stock #980J
Spec sheet: THERMOTRON SM-32C Production Chambers, Temperature Chambers spec sheet

AGREE Chambers, CO2 LN2 Chambers, Temperature Chambers CC 965J THERMOTRON PCH-810-LN2 Used THERMOTRON PCH-810-LN2

Thermotron Portable Temperature Conditioner For Remote Heating or Cooling
Model #PCH810-LN2

SPECS: O.D. 40"W X 33"D X 70H
Temperature Range: -70 to +150 Deg. C
Has Stand and Castors
6" Dia. Intake - 6" Dia. Exhaust
2 Hot/Cold Exhaust Tubes Included
Power: 480V, 3Ph, 22 Amps

This Thermotron Portable Temperature Conditioner is used to simulate conditions a product may encounter in actual use but may be too large for a traditional Test Chamber. This unit provides forced air cooling to a remote test enclosure. With the Modern Thermotron Model #8800 Touchscreen Programmer you can control air flow, temperature, and volume to recreate the environmental conditions your product may encounter. Can also be used inside of an AGREE chamber for maximum testing conditions. For use in Aerospace Electronics Testing, Automotive Testing – Test an Entire Vehicle at once – and general research and development labs for new and upcoming products. Purchasing this PreOwned – Warrranteed Portable Temperature Conditioner will also save money on your total R & D costs.

Stock #965J
Spec sheet: THERMOTRON PCH-810-LN2 AGREE Chambers, CO2 LN2 Chambers, Temperature Chambers spec sheet

CO2 LN2 Chambers, Temperature Chambers CC 963J THERMOTRON P-CH-810-LN2 Used THERMOTRON P-CH-810-LN2

This Is A Thermotron LN2 Cooling System Consisting
of 2 Separate Units - A Portable Temperature Conditioner And A Separate Chest Chamber For Remote Product Testing. Heating and Cooling Samples, Parts, Various Testing. The Temperature Conditioner Connects With 2 Large Hot/Cold Transfer Tubes Which ARE Included And Are In Excellent Condition! The Portable Temperature Conditioner Includes An Easy To Use Touchscreen Programmer

SPECS:
Portable Cooling Unit: O.D. 40" X 33" X 70"
Temperature Range: -70 to +150 Deg. C
480V - 3 Ph, - 22 Amps
Has Thermotron Model #8800 Touchscreen Programmer With Over Temperature Protection, Castors, 6" Dia. Intake - 6" Dia. Exhaust - Tubes Included

SEPARATE CHEST CHAMBER:
I.D. 29"W X 19"D X 3.5" H
O.D. 53"W X 52"D X 58"H

UNITS CAN BE SOLD SEPARATELY - SPECIFY WHICH
PIECE YOU WOULD LIKE A QUOTE ON

Stock #963J
Spec sheet: THERMOTRON P-CH-810-LN2 CO2 LN2 Chambers, Temperature Chambers spec sheet

Agree Chambers, CO2 LN2 Chambers, Halt Chambers, Temperature Chambers CA 961J THERMOTRON F-32-CHV-LN2 Used THERMOTRON F-32-CHV-LN2

Thermotron Test Chamber Model #F-32-CHV-LN2

SPECS:
I.D. 40"W X 40"D X 36"H
O.D. 64"W X 54"D X 108"H
Temperature Range: -70 to +170 Deg. F - LN2 Cooled
Fast Ramp: -54C to +71C 10 Deg. C Per Minute
+71C to -54C 10 Deg. C Per Minute
Programmer Remote Console - Thermotron 4800
Over and Under Temperature Protection
Stainless Steel Interior
Honeywell Paper Chart Recorder
Viewing Windows, Interior Light, 2 Door Pass Thru
Solid Floor
Power: 208V, 3Ph, 123 Amps

This Thermotron Test Chamber was originally designed as an AGREE Chamber with front and rear doors but with the solid installed floor can be also used as a Fast Ramp Temperature Test Chamber. It has been reconfigured with LN2 and boosted elements to meet fast ramp requirements of 10 Deg. C per minute (limited range). This Test Chamber has a separate control console with a Thermotron Model #4800 Programmer, High-Low Limit, Honeywell Chart Recorder, and comes with a Custom Operating Manual

SOME OPTIONS AVAILABLE: A Plenum floor to fit over a vibration system,
Watlow Touch Screen Programmer - Options that can installed by our Qualified Test Chamber Experts

Stock #961J
Spec sheet: THERMOTRON F-32-CHV-LN2 Agree Chambers, CO2 LN2 Chambers, Halt Chambers, Temperature Chambers spec sheet

Humidity Chambers, Production Chambers, Temperature Chambers, Temperature Humidity Chambers CH 917J THERMOTRON SML-1500-25-25 Used THERMOTRON SML-1500-25-25

Thermotron Temperature Humidity Test Chamber
Model #SML-1500-25-25

SPECS AND INCLUDED OPTIONS:
I.D. 52"W X 35"D X 47"H
O.D. 74"W X 91"D X 97"H
Temperature Range: -65 to +170 Deg. C -
Remote Air Cooled
Condenser not included.
Fast Ramp
10% to 98% Humidity
Thermotron Model 8800 Programmer
Over and Under Temperature Protection
Envirionmentally Friendly Refrigerants
Stainless Steel Interior
Honeywell Truline Recorder
Viewing Window, Interior Light, 2 Shelves
2X 6" Dia. Opposing Side Ports
Side Access Door
Power: 480V, 3Ph, 125 Amps

Stock #917J


Production Chambers, Temperature Chambers CT 903J THERMOTRON S-16 Used THERMOTRON S-16

Thermotron Temperature Test Chamber
Model #S-16

SPECS:
I.D. 30"W X 30"D X 30"H
O.D. 50"W X 58"D X 82"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Watlow EZ-Zone Programmer - Completely Configured For Immediate Use!
Over and Under Temperature Protection
Environmentally Friendly Refrigerants
Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAILABLE - PLEASE INQUIRE
Power: 230V, 1Ph, 60 Amps

Stock #903J
Spec sheet: THERMOTRON S-16 Production Chambers, Temperature Chambers spec sheet

CO2 LN2 Chambers, Production Chambers, Temperature Chambers CC 899J THERMOTRON PCH810-CO2 Used THERMOTRON PCH810-CO2

Thermotron Portable Temperature Conditioner For Remote Heating or Cooling
Model #PCH810-CO2

SPECS:
O.D. 44"W X 43"D X 57"H
Temperature Range: -70 to +150 Deg. C
CO2 Cooled - Can Be Upgraded to LN2
Thermotron Model #8800 Programmer
Includes Stand and Castors
5HP Motor
6" Dia. Intake - 6" Dia. Exhaust
Power: 208V, 3Ph, 45 Amps

This Thermotron Portable Temperature Conditioner is used to simulate conditions a product may encounter in actual use but may be too large for a traditional Test Chamber. This unit provides forced air cooling to a remote test enclosure. With the Modern Thermotron Model #8800 Touchscreen Programmer you can control air flow, temperature, and volume to recreate the environmental conditions your product may encounter. Can also be used inside of an AGREE chamber for maximum testing conditions. For use in Aerospace Electronics Testing, Automotive Testing – Test an Entire Vehicle at once – and general research and development labs for new and upcoming products. Purchasing this PreOwned – Warrranteed Portable Temperature Conditioner will also save money on your total R & D costs.

Stock #899J
Spec sheet: THERMOTRON PCH810-CO2 CO2 LN2 Chambers, Production Chambers, Temperature Chambers spec sheet

Production Chambers, Temperature Chambers CT 895J THERMOTRON S-16 Used THERMOTRON S-16

Thermotron Temperature Test Chamber
Model #S-16 SALE PENDING

SPECS:
I.D. 30"W X 30"D X 30"H
O.D. 48"W X 52"D X 84"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Has Programmer, Over and Under Temperature Protection
Stainless Steel Interior, Environmentally Friendly Refrigerants
Includes Viewing Window, Interior Light, Castors
1 Shelf, 2X 3.875" Dia. Opposing Side Feed-Thru Ports
Power: 230V, 1Ph, 44 Amps

Stock #895J


Spec sheet: THERMOTRON S-16 Production Chambers, Temperature Chambers spec sheet

AGREE Chambers, CO2 LN2 Chambers, Production Chambers, Temperature Chambers CA 879J THERMOTRON F32LN2 Used THERMOTRON F32LN2

Thermotron LN2 AGREE Chamber Model #F32LN2

SPECS:
I.D. 40"W X 40"D X 36"H
O.D. 71"W X 54"D X 94"H
Temperature Range: -70 to +170 Deg. C - LN2 Cooled
Watlow Model #F-4 Programmer
Over and Under Temperature Protection
Stainless Steel Interior
Honeywell Truline Recorder
4X 2.75" Dia. Feed-Thru Ports, 1X 5.75" Dia. Feed-Thru Port,
2X 6" Dia. Feed-Thru Port
Power: 480V, 3Ph, 45 Amps

Stock #879J
Spec sheet: THERMOTRON F32LN2 AGREE Chambers, CO2 LN2 Chambers, Production Chambers, Temperature Chambers spec sheet

Temperature Chambers, Temperature Humidity Chambers CH AA77 THERMOTRON SM-16C Used THERMOTRON SM-16C

Thermotron Temperature Humidity Test Chamber Model SM-16C
I.D. 30"WX 30"D X 30"H
O.D. 49"W X 58"D X 84"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Humidity: 20% to 95%
Watlow #F-4 Programmer, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAILABLE - PLEASE INQUIRE
Power: 230V, 3Ph, 40 Amps

Stock #AA77
Spec sheet: THERMOTRON SM-16C Temperature Chambers, Temperature Humidity Chambers spec sheet

CO2 LN2 Chambers, Furnaces, Humidity Chambers, Industrial Ovens, Batch Ovens, Laboratory Ovens, Hi Temp Ovens, High Vacuum Ovens, Cleanroom Ovens, Curing Ovens, Inert Gas Ovens, Production Chambers, Temperature Chambers, Temperature Humidity Chambers CT SHLV THERMOTRON SHELVES Used THERMOTRON SHELVES

We Provide Industrial Oven Shelves For Almost Any
Unit You May Have - Ovens - Test Chambers, Etc.
Anything We Don't Have In Stock We Can Have
Custom Created - And At Significantly Lower Prices
Than Any Vendors You May Normally Use!

Contact Us With Your Dimensions For A Quick Quote!
Fits Blue M - Thermotron - Delta Design - Tenney,
Just To Name A Few......

Production Chambers, Temperature Chambers, Cryogenic Chambers CH 750J THERMOTRON S-32 Used THERMOTRON S-32

Thermotron Temperature Test Chamber
Model #S-32

SPECS:
I.D. 38"W X 38"D X 38"H
O.D. 62"W X 66"D X 89"H
Temperature Range: -65 to +170 Deg. C
Watlow Programmer
Over and Under Temperature Protection
Environmentally Friendly Refrigerants
Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
2X 6" Dia. Door Feed-Thru Ports, 1X 6" Dia. Side Feed-Thru Port
Power: 230V, 1Ph,

Stock #750J

Production Chambers, Temperature Chambers CT 635J THERMOTRON S-4 Used THERMOTRON S-4

Thermotron Temperature Test Chamber Model #S-4
I.D. 20"W X 20"D X 20"H
O.D. 36"W X 44"D X 72"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Thermotron Programmer, Over Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAILABLE - PLEASE INQUIRE
New Compressor, 2X 7.75" Dia. Side Feed Thru Ports
Power: 230V, 1Ph, 30 Amps

Stock #635J
Spec sheet: THERMOTRON S-4 Production Chambers, Temperature Chambers spec sheet

Production Chambers, Temperature Chambers CT 615J THERMOTRON S-16C Used THERMOTRON S-16C

Thermotron Temperature Test Chamber Model #S-16C
SALE PENDING...

Specs:
I.D. 30"W X 30"D X 30"H
O.D. 46"W X 56"D X 92"H
Temperature Range: -70 to +170 Deg. C - Air Cooled
Watlow EZ-Zone Programmer, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, 1 Shelf
ADDITIONAL SHELVES AVAILABLE - PLEASE INQUIRE
2X 6" Dia. Door Feed-Thru Ports, 2X 4" Dia. Side Feed Thru-Ports
New Compressor
Power: 208V, 3Ph, 30 Amps

Stock #615J
Spec sheet: THERMOTRON S-16C Production Chambers, Temperature Chambers spec sheet

Humidity Chambers, Production Chambers, Temperature Chambers, Temperature Humidity Chambers CT MOTOR THERMOTRON MOTOR Used THERMOTRON MOTOR

In Stock are these Replacement Motors for Thermotron Test Chambers
These Motors Work as a replacement motor on Most Thermotron Chambers, however we
suggest you contact us to confirm it will work on your Model
Sales@LRE.com or 800-574-2748 323-770-0634
The Motors are NEW - Not Used
Motor Dimensions: 3.8" X 5.1" with 5/16" X 7.5" Shaft
Top 3" of Shaft Flat on One Side
CWLE Stainless Steel Shaft
Power: 115/230V, 2.2/1.2 Amps, 50/60 Hz, 3000 RPM

$429.99 Each

Production Chambers, Temperature Chambers CT 580J THERMOTRON SE-300-2-2 Used THERMOTRON SE-300-2-2

Thermotron Temperature Test Chamber Model #SE-300-2-2

SPECS:
I.D. 24"W X 26"D X 28"H
O.D. 44"W X 68"D X 77"H
Temperature Range: -65 to +170 Deg. C (Air Cooled)
Watlow Programmer, Over and Under Temperature Protection

Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Viewing Window, Interior Light, Castors, Shelf
2X 3.75" Dia. Side Ports
Power: 208V, 3Ph, 70 Amps

Stock #580J
Spec sheet: THERMOTRON SE-300-2-2 Production Chambers, Temperature Chambers spec sheet

Humidity Chambers, Production Chambers, Temperature Humidity Chambers CH 532J THERMOTRON SM-8C Used THERMOTRON SM-8C

Thermotron Temperature Humidity Test Chamber Model #SM-8C
I.D. 24"W X 24"D X 24"H
O.D. 44"W X 50"D X 72"H
Temperature Range: -70 to +170 Deg. C
Humidity Range: 20% to 95%
Watlow #F-4 Programmer, Over and Under Temperatue Protection
Electronic Sensor
Environmentally Friendly Refrigerants, Stainless Steel Interior
Viewing Window, Interior Light, Castors, Shelf
Power: 240V, 1Ph, 30 Amps

Stock #532J
Spec sheet: THERMOTRON SM-8C Humidity Chambers, Production Chambers, Temperature Humidity Chambers spec sheet

AGREE Chambers, Production Chambers, Temperature Chambers, Temperature Humidity Chambers, Steady State Chambers CA 432J THERMOTRON F-40CHMV-25-25-2 Used THERMOTRON F-40CHMV-25-25-2

Thermotron AGREE Chamber Model #F-40CHMV-25-25-2

SPECS
I.D. 40"W X 38"D X 44"H
O.D. 82"W X 112"D X 95"H
Temperature Range: -65 to +170 Deg. C
Humidity Range: 20% to 95%
10 Deg. C Per Minute Non-Linear
Temperature Ramp Rate: -54 to +71 Deg. C
Water flow:Minimum 28 Gallons per minute @ 75F
Programmer, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
2X 6" Dia. Side Ports, Door Notch
Viewing Window, Shelf
Power: 460V, 3Ph, 150 Amps

Stock #432J

Total Results: 50 [viewing 1 to 25] 1 2
