| Production Chambers/ Temperature Chambers |
CT |
858J |
ESPEC |
HC-120 |
15 |
12.6 |
3.9 |
|
Espec Fast Ramp Board Tester
Model #HC-120
SPECS:
I.D. 15"W X 12.6"D X 3.9"H Drawer
O.D. 33"W X 42"D X 45"H
Temperature Range: -60 to +150 Deg. C - Air Cooled
Ramp Rate: 6 to 9 Deg. C Per Min. +150 to -60
Espec Programmer
Environmentally Friendly Refrigerants, Stainless Steel Interior
Power: 220V, 3Ph
Stock #858J
|
|
|
| Thermal Shock Chambers |
CZ |
835J |
ESPEC |
THERMAL SHOCK CHAMBE |
20 |
20 |
16 |
|
Espec Mechanical Thermal Shock Test Chamber
Model #ETS04-1SW
I.D. 20" X 20" X 16"
O.D. 70" X 98" X 98"
Temperature Range: -73 to +200 Deg. C - Water Cooled
7 GPM @ 24 Deg. C
Watlow Model #F-4 Programmer, Over and Under Temperature Protection
Environmentally Friendly Refrigerants, Stainless Steel Interior
Includes Honeywell Truline Chart Recorder, 4 Shelves
Cold Zone: -73 to +40 Deg. C
Hot Zone: Ambient to +200 Deg. C
Power: 480V, 3Ph, 60 Amps
Stock #835J
|
Spec sheet:
|
|
| Humidity Chambers/ Temperature Chambers/ Temperature Humidity Chambers |
CH |
126I |
ESPEC |
PLA-4AP |
39 |
35 |
39 |
|
Espec Temperature Humidity Test Chamber Model PLA-4AP
Internal Chamber Dimensions: 39"W X 35"D X 39"H
Temperature Range: -40 to +150 Deg. C (single stage air cooled compressor)
Humidity Range: 20% to 95% RH (wet sock humidity sensor)
Model EY-101 Programmable Temp/Humidity Controller
Stainless Steel Interior, No Window, Shelf Included
2X 3.25" Diameter Feed-Through Ports in Side Walls
New Environmentally Friendly Refrigerants
Power: 208/230V, 3Ph, 40 Amps
Stock #CH-126i
|
Spec sheet:
|
|
| Temperature Chambers |
CT |
761F |
ESPEC |
ET33-CPW |
29 |
29 |
65 |
|
Espec Fast Ramp Temperature Chamber Model ET33CPW
Internal Chamber Dimensions: 29"W X 29"D X 65"H
Temperature Range: -20 to +150 Deg. C (single stage WATER COOLED compressor)
New Watlow Programmable Temperature Controller Installed (3 Year Watlow Warranty)
Over and Under Temperature Protection Controller
Stainless Steel Interior
2X 4" Diameter Feed-Through Ports in Side Walls
Castors for Easy Movement of Chamber
New Environmentally Friendly Refrigerants
Power: 208/230V, 3Ph, 50 Amps
Stock #761F
Additional Options Available:
Touchscreen Control
Paperless Data Logger
Can Be Retrofitted for Remote Air Cooling
|
|
|
